Main Spec

Projector Type

DLP®Chip×1,DLP Display

Chip Size

0.67''

Native Resolution

1920×1200

Brightness

15,000 Lumens

Uniformity*2

90%

Contrast*2

12000:1

Aspect Ratio

16:10:Native / 4:3 Compatible

Light Source

Type

RgBL Laser Technology

Life

Standard :20000 hours Eco Mode:25000hours

projector lens

Projector Lens

A06: 1.22-1.53:1(STD) /A13 2.90-5.50:1/A1 0.57:1

Throw Ratio

(0.36~5.50)

Keystone Correction

H

±20°

V

±20°

Projection Method

Ceiling,Front,Rear

Input

DVI-Dx1

HDMI 1.4(SupportHDCP*3)x1

15-pin Mini-Dsubx1

HDBaseT*4x1

Wired Remote x1 3.5mm

RJ45×1(LAN Control)

RS232(D-sub 9pin)x1

miniUSBx1

USB-A x1

Output

15-pin Mini-Dsubx1

HDMI 1.4(Support HDCP*3) OUTx1

3D-Sync x1

Power Input( Voltage&Frequency)

100-240V AC±10%,50/60Hz

Power Consumption

Normal:770W,ECO:395W

Case Material

Molded Plastic

Standby Power Consumption

＜0.5W

Dimension DxWxH

484mm(W)×519mm(D)×181mm(H)

Net Weight

About 25kg

Noice

Normal:35dB ECO:33dB

Working Temperature*5

High Altitude

0m-2500m(>1500m Using High Altitude Mode)

Temperature

5-40℃,

Humidity

10%-85%

Accessories

AAA Battery ×2,Remote Control ×1,Power Cable×1,VGACable ×1,CD-ROM(User Manual)×1, Quick installation manual, warranty card, Lens cover

Comments:

1. The optical output data value is measured in the center of the projected image.
The measurement method is based on the international standard ISO/IEC 21118:2012 and the data values are averages.

2. ISO21118 standard, the data value is average.

3. HDCP/ HDCP (High-bandwidth Digital Content Protection)

4.HDBaseT

5. If using the projector in an elevated area ambient temperature exceeds 35°C;
The lifespan of the lens may be reduced. It is recommended to keep the temperature as low as possible.
