| Resolution | XGA Support 4k decoding |
| Brightness | 5500 ANSI lumens |
Overall Spec |
Panel | Display Panel | 3x0.63” with MLA |
Display Technology | Liquid Crystal Display |
Native Resolution | XGA(1024 x768) |
Light source Life time | Normal mode | 20000hrs |
ECO mode | 20000hrs |
ECO2 mode | 30000hrs |
Projection Lens | Lens Vendor | Fijifilm Lens |
F | 1.7~2.21 |
f | 17.42~28.99mm |
Zoom/Focus | Manual |
Throw Ratio | 1.3(wide)-2.2(tele) |
Zoom Ratio | 1.66 |
Screen size | 30-300 inch |
Lens Shift | V:＋50%～0%,
H:±28% |
CR | Contrast Ratio
(FOFO) | 5000000:1 |
Noise | Noise(dB) | 37dB(Normal) 29dB(ECO1)
27dB(ECO2) |
Uniformity | Uniformity(Actual Min)
-JISX6911 | 90% |
AR | Aspect Ratio | Native:4:3 Compatible: 16:9 |
Terminal(I/O port) |
Input | VGA | *1 |
HDMI 1.4B(IN) | *2 |
USB-A | *1 |
USB-B | *1(Display) |
RJ45 | *1(Display) |
HD BaseT | *1(Optional) |
Audio in
(mini jack,3.5mm) | *1 |
Output | VGA | *1 |
Audio out
(mini-jack,3.5mm) | *1 |
Control | RS232 | *1 |
RJ45 | *1 (Control) |
USB-B | *1 (For upgrade) |
General Spec |
Audio | Speaker | 16W*1 |
Dust filter | W/Filter |
Filter Life time | 8000h |
Power Consumption | Power Requeirements | 100~240V 50/60Hz |
Power Consumption
(Normal) (Max) | 350 |
Power Consumption
(ECO1) (Max) | 270 |
Power Consumption
(ECO2) (Max) | 230 |
ECO Standby Mode Power Consumption | <0.5W |
Temp.&Humidity | Operating Temp. | 5 to 40deg.C |
Operating Thumidity. | 20-80% |
Store Temp. | ‘-10 to 50deg.C |
High altitude | 0~3000m |
Other Functions |
Keystone | Keystone Correction
(Lens@center) | V: ±30°
H:±30°
Pincushion/Barrel Correction 6 Corner Geometry correction 4 Corner
Correction
Grid image tune |
OSD | Languages | 26 language |
LAN Control | LAN Control-RoomView (Crestron) | Yes |
LAN Control--
AMX Discovery | Yes |
LAN Control-- PJ Link | Yes |
Scanning Frequency | H-Synch Range | 15~100KHz |
V-Synch Range | 24~85Hz |
Display Resolution | Computer Signal Input | VGA, SVGA, XGA, SXGA,WXGA,UXGA,WUXGA,4K@3
0Hz |
Video Signal Input | 480i, 480p, 576i, 576p, 720p, 1080i
and 1080p |
SW setting | Auto Setup | INPUT SEARCH,AUTO PC,Auto
Keystone |
Blank | Yes |
Suspend | Yes(5miniutes no singnal as default) |
Picture mode | Dynamic,Standard,Cinema, Colorboard,sim-DICOM
,Blackboard(Green) |
Cooling time | 0s, Normal,60s |
Closed caption | Yes |
Auto Ceiling | Yes |
D-Zoom | 1~33 |
Others | 360° projection | Yes |
Wireless display无线投屏 (Optional) | SmartPhone:
Android:Install APK for Android
iphone: Airplay function
PC投屏:
Support WiFi Display@Windows&MAC system
through dongle |
Dimension&Weight |
| MAX Dimensions
(WxHxD mm) | 405*358*137 |
| Net. Weight (KG) | ~7.7KG |
| Packaging Box Dimensions
(WxHxD mm) | 510*498*260 |
| Gross. Weight (KG) | ~10.2KG |
Accessory |
| Manual Languages | Chinese,English |
| Standard Accessaries | Power cord(EU)/power cord
(Ja)
Remote control&RC Battery |
Regulation List |
China | CCC | √ |
WW | CB | √ |
US | cTUVus | √ |
FCC | √ |
FDA | √ |
EU | CE-EMC | √ |
CE-LVD | √ |
CE-ERP | √ |
激光等级认证 | 等级1 | √ |
EMC Class |
| EMC Class | Class A@3dBm |
