| Key part | Panel | LCX183A-(B11 DML)
W/ Micro Lens |
| PJ Lens | F1.6x1.2 |
| Light source | Philips:225W Infinity(Lamp) |
| Main IC | Pixworks: PWC878 |
| Sony IC | CXD3553+CXA3832 |
| Brightness | Brightness (Type) ( Ansi Lumens ) | 4000 |
| Power consumption(MAX) | 320 |
| Light source | Lamp:225W |
| Overall Spec |
| | Display Panel | 3x0.64” |
| Panel | Display Technology | Liquid Crystal Display |
| | Native Resolution | WUXGA (1920 x 1200) |
| Lamp | Lamp Consumption(W) | Philips:225W Infinity(Lamp) |
| Lamp Lifetime(H) | 10000H(Normal) /20000H(ECO) |
| | Zoom/Focus | Manual |
| | Throw Ratio | 70"@2.067m；1.37--1.65:1 |
| | F | F:1.6~1.76 |
| Projection Lens | f | f=19.158~23.018mm |
| Zoom Ratio | 1.2x optics |
| | Screen size | 0.872~10.736m(30"~300") |
| CR | Contrast Ratio(Min) | 15000:1 (w/IRIS) |
| Noise | Noise(dB)@1m | ECO: 30dB
Normal: 37dB |
| Uniformity | Uniformity(Actual Min)
-JISX6911 | 90% |
| AR | Aspect Ratio | 16:10 (Standard)/4:3(Compatible) |
| Terminal(I/O port) |
| | VGA | *1 |
| | HDMI | *2 |
| | Video | *1 |
| | Audio in
(mini jack,3.5mm) | *1 |
| Input | Audio in(L/R)
--RCA | *1 |
| | USB-A 2.0 | *1 |
| | USB-B | *1(Display) |
| | RJ45 | *1(Display) |
| Output | VGA | *1 |
Audio out
(mini-jack,3.5mm) | *1 |
| Control | RS232 | *1 |
| RJ45 | *1 (Control) |
| USB-B | *1(for up-grade) |
| General Spec |
| Audio | Speaker | 1*10W |
| Power Consumption | Power Requeirements | 100~240V@ 50/60Hz |
| Power consumption (W) | 320 |
| Power Consumption (ECO) | 224 |
| ECO Standby Mode Power Consumption | <0.5W |
|
| Network standby Power Consumption | <2W |
| Temp.&Humidity | Operating Temp. | 0℃~40℃(35~ ECO) |
| Store Temp. | -10℃~~55℃ |
| Oparating Humidity | 20%~85% |
| Storage Humidity | 10%~85% |
| Mechanical Design | Security bar | Yes |
| Password protections | Yes |
| Control Panel Lock | Yes |
| Kenginston Lock | Yes |
| Ventilation (In/Ex) | Side/Side |
| Lamp access | Top |
| Filter access | Side |
| Dust filter | ESD filter(静电) |
| Keystone | Keystone Correction | V: ±30°(auto+manual) H:±15°(manual) Corner Keystone |
| OSD | Languages | 26 languages: English, German, French, Italian, Spanish, Polish,
Swedish, Dutch
,Portugese, Japanese, Simplified Chinese, Traditional Chinese,
Korea, Russian, Arabic, Turkish, Finnish, Norwegian, Danish,
Indonesian, Hungarian, Czech, Kazak,Vietnamese,Thai, Farsi |
| LAN Control | LAN Control-RoomView (Crestron) | Yes |
| LAN Control-AMX Discovery | Yes |
| LAN Control-PJ Link | Yes |
| Scanning Frequency | H-Synch Range | 15~100KHz |
| V-Synch Range | 48~85Hz |
| Display Resolution | Computer Signal Input |
| VGA, SVGA, XGA, SXGA,WXGA,UXGA,WUXGA,Mac, |
|
| Video Signal Input | NTSC, NTSC4.43, PAL, SECAM, PAL-M, PAL-N, |
|
| SW setting | Auto Setup | INPUT SEARCH,AUTO PC,
AUTO Keystone |
| Audio muting(Muting) | Yes |
| Suspend | Yes(5miniutes no singnal as default) |
| Picture mode | Dynamic,Standard,Cinema, Blackboard,Colorboard |
| Lamp mode | NORMAL,ECO |
| Filter Cleaning Cycle | 100/200/300 hours |
| Cooling time | 0S,60s,90s |
| Closed caption | Yes |
| High altitude | Yes(1400~2700m) |
| Signal Power On | Yes |
| Turn on countdown | Customized-(5S, 10S, 30S..) |
| Auto Ceiling | Yes |
| D-Zoom | 1~33 steps |
| Dimension&Weig | Others |
| MAX Dimensions (WxHxD mm) | 345*261*99 |
| Net. Weight (KG) | ~3.26 |
| Packaging Box Dimensions (WxHxD mm) | 442(L) X 386(W) X 195mm(H) |
| Gross. Weight (KG) | 4.7 |
| Accessory |
| Regulation List | Standard Accessaries | Power cord, VGA cable, Remote control |
| China | Safety and EMC | CCC |
| 节能环保 | CECP |
| USA/Canada | Safety | cTUVus |
| CB |
| EMI | FCC |
E.U
EMC Class | EMC | CE |
| EMC class | Class B@3dB |
