3400 ASNI Lumens Ultra Short Throw Projector High Contrast Ratio
2550000:1 high contrast ratio 3400 ASNI lumens Ultra Short Throw
DLP 4K Projector For Educational Projection SNP-AH340UT
Motorized focus lens center design
The SNP-AH360UT projector uses a motorized focus lens. which can
precisely adjust the focus of the lens through the motor And it can
maintain accurate focus for a long time without worrying about the
problem of out of focus. The lens is centered, the center of
gravity of the projector is centered, and the projector's position
can be maintained for a long time. It is convenient to install with
electronic whiteboard and beautiful to use.
ultra-quiet design
the sound of the operation of the whole machine (Standard mode) was
regulated below 30 decibels, making our demonstration quieter.
Split screen splicing function
The SNP-AH360UT projector has a built-in split-screen function.
which can realize the split screen function of multiple projectors
without adding any accessories. Enjoying the big screen is no
longer a luxury.
Versatile port design for multiple connection methods.
Including 2 HDM interfaces, 2 VGA interfaces for computers, etc.
The diversified interface design supports a variety of system
applications.
Automatic keystone correction Support free 360° angle installation
Optimized functionality ±40° vertical keystone correction with
digital zoom function Installation methods such as front projection
rear projection lifting and splicing can be selected according to
the place of use Support 360° free angle installation and fully
meet various creative applications.
3D display at your fingertips
Support DLP Link3D to share stereo
DICOM emulation mode
High resolution X-ray images can be created to meet the
requirements of medical teaching.
High-definition laser display, projecting a "real world" image.
Stable laser light source is matched with 1080P display chip, the
image roughness is small. The edges of the image are more delicate.
and the large projection screen has a good visual effect.
High contrast, high color gamut.
2,550,000:1 high contrast display, fine grayscale display, natural
layer transitions, clear highlights and black level details,
projecting clear and crisp images. The application of ALPD laser
display technology increases the color gamut coverage of the
projector. The color gamut of the SNP-AH360UT series projectors
reaches or exceeds the REC.709 color gamut standard. What You Get
As you can see!
stable image quality long highlight
Using ALPD laser display technology, the laser light source has a
lifespan of more than 25,000 hours and a small attenuation range.
This ensures that the projector outputs high brightness. high color
saturation and clear images for a long time
Ultra-short-focus projection, big screen in small space
The projection ratio of the SNP-AH360UT projector reaches 0.23:1,
breaking the projection distance limit. Projection distance of 100"
screen is only 19 cm*. The speakers will not dazzle anymore. And
the audience will feel the comfort and shock of the big screen.
| Item | Spec | SNP-AH340UT |
Optical Parametric
光学性能 | Display Technology
显示技术 | DLP |
Native Resolution
分辨率 | 1920×1080 |
Brightness
亮度 | 3400 ANSI |
Uniformity
均匀性 | 85% |
Contrast Ratio
对比度 | 2,550,000:1 |
Throw Ratio
投射比 | 0.233 |
Aspect Ratio
宽高比 | 16:9 (Standard)/16:10(Compatible)/4:3 (Compatible) |
Screen size
屏幕尺寸 | 80-100 inch |
Keystone Correction
梯形校正 | V:±40° (Auto) |
Light Source
光源 | Type
类型 | ALPD |
Lifetime(H)
寿命(H) | 25000 H |
Electric Property
电气参数 | Standby Mode
Power Consumption
待机功率 | <0.5W |
Power Consumption
电源功率 | 340W |
Power Input
输入电压 | 100-240V |
Power Frequency
电源频率 | 50/60Hz |
Noise
噪音 | <30dB |
Speaker
喇叭 | 10W |
Physical Parameter
物理参数 | Dimensions
尺寸 | 425*330*105mm |
Weight
重量 | 6kg |
Environmental Parameter
环境参数 | Operating Temp.
工作温度 | 0~40°/35~40°( ECO) |
Oparating Humidity
工作湿度 | 20%~80% |
Storage Temp.
储存温度 | -20℃~60℃ |
Storage Humidity
储存湿度 | 10%~90% |
High Altitude Mode
高海拔模式 | Yes |
Common Port
通用接口 | Video Port
视频端口 | Input: HDMI×2; RGB×2(RGB IN 2 Share with RGB Out); Video(RCA)×1;
S-Video×1;
Output: RGB×1 |
Audio Port
音频端口 | Input: Audio in(L/R)--RCA×1; Audio in(mini jack,3.5mm)×1; MIC ×1;
Output: Audio out(mini-jack,3.5mm)×1 |
Control Port
控制端口 | RS232×1; LAN(RJ45)×1; USB(type B only for debug)×1 |
Signal Compatible
信号兼容 | Digital Signal
数字信号 | 1080p, up to WUXGA(1920×1200@60Hz) |
Analog Signal
模拟信号 | up to UXGA(1600×1200@60Hz) |
Component Video
分量视频 | 1080p/1080i/720p/576p/576i/480p/480i |
Composite Video
复合视频 | NTSC-M/NTSC 4.43/PAL/PAL-M/PAL-N/SECAM |
Other Function
其他功能 | 1. 18 OSD languages;
2. 3D function;
3. Lens centered design;
4. DICOM mode;
5. One-key mute;
6. Screen segmentation;
7. Quick switch;
8. High altitude mode;
9. Electric focus
10. Automatic signal search;
11. Automatic keystone correction;
12. The screen freezes;
13. Auto black screen |
