300 ANSI Lumens DLP Interactive Projectors With Android Systems
DLP Interactive Projector Smart Touching 300 ANSI Lumens With
Android Systems
Creating for life and growing with perfection
Specifications and Functions
- Brightness :300 ANSI Lumens
- Projection size 20”~100”
- Weight About 1kg
- Focus Auto focus
- Image correction Auto keystone correction
- System Android 8.1
- Transmission Wi-Fi / Miracast / USB / Bluetooth / HDMI / 4G
- Control Remote control, stylus, and finger touching
- Battery capacity 5000 mAh
- Pixel 1280*720 1080P/2K/4K supported
Simple & UniqueDesign
Simplicity and uniqueness are our key design elements. The
appearance of arcs and smooth curves give people with friendly and
comfortable feelings.
A variety of colors is more eye-catching; and it can be freely
matched with different places and spaces allowing you to use them
in your life more as you like.
We Can Do More
Product applications-We can do more
1280*720
1080P/2K/4K
suppor300 lumens
What We Offer
We are offering you more support and compatibility
10-point Anytouch System
10-point finger touching function system
Custom Android UI
Mobile user interface system
UP to 100 inch HD screen
100-inch HD screen
Built-in Microphone
A remote control supporting microphone
True 720p with 4K Support
High definition of 4K high resolution
Miracast
A wireless video router device supported
5000mah Built-in battery
A large capacity battery of 5000mAh built in
Automatic Keystone Correction
Auto keystone correction
Wi-Fi/Bluetooth Compatible
Wi-Fi and Bluetooth built in
Speakers Compatible
Speakers built in
We are More Than You Think
Smart touching projection can also replace the boring tablet
learning devices. It has a larger touching projection screen and an
active learning method to enhance its effectiveness. It is a
brand-new type of home parent-child learning and entertainment
device. The screen becomes larger and clearer; and it also allows
the family to play together to promote parent-child interactions.
Classification | Project | Specification Description | Specifications | Remarks |
Exterior | Material |
| PC MN3600H |
|
Color scheme |
| Lake blue, obsidian white |
|
Switch button | Power ON/OFF, volume +/- | Switch machine button support |
|
Status light display |
| Single color light |
|
Working environment temperature/humidity | Working environment |
| 0 ~ 35 0 C / Humidity 90% |
|
Noise | Machine noise |
| Whole machine ≤ 32db (distance:1M) |
|
Machine | Optics | Display technology |
| 0.3 720P SubLVDS Series 245 DMD |
|
LED light source |
| Q8WP/ KP CSLPM1.F1 LED,Osram |
|
Light machine center brightness |
| >250 ANSI<300 |
|
Light source life |
| >10,000 Hr |
|
Contrast |
| 600:1 |
|
Color gamut |
| >= 100% NTSC |
|
Evenness |
| 85% |
|
Color temperature |
| 7,500K |
|
Lens material |
| High light transmission coating lens |
|
Throw ratio |
| 0.39 : 1 |
|
Resolution |
| 1280*720P (Support 1080P, 2K, 4K) |
|
Maximum resolution |
| 720P |
|
Focus method |
| Auto focus / manual focus |
|
Best projection distance |
| 173mm-331mm |
|
Projection size |
| 23 -100 inches |
|
Projection method |
| Table / Front/ Rear/ Ceiling |
|
Offset |
| Offset 149% above |
|
Keystone correction |
| Vertical ±40° |
|
| Level ±40° |
|
Aspect ratio |
| 16:9 |
|
Primitive mode |
| RGB |
|
| Core specificat | CPU | Dual Cortex-A72 + Quad Cortex-A53 |
|
|
electronic | ions | GPU | Mali-T860 GPU |
|
RAM | 4 GB DDR3 |
|
Memory | 32G B eMMC |
|
| G Sensor gravity sensor device | STK 850 |
|
operating system | Android 8.1 and above |
|
System power | Power consumption | 20-40W |
|
OS | System UI | Pointdidi UI |
|
System OS | Android 8.1 |
|
Output | Input power DC | DC IN × 1 |
|
Machine |
| Output | HDMI input into | HDMI 2.0 × 1 |
|
Mirror output | Miracast |
|
USB port | USB 2.0 × 1 |
|
Headphone audio output | 3.5mm ×1 AV out audio output interface, OMTP/CTIA earphone standard
(three-segment earphones do not support earphone Mic function) |
|
Wireless network | WIFI module | 2.4G/5GHz dual frequency 802.11 a/b/g/n/ac
2 x 2 Dual a ntenna, dual transmission and reception |
|
BT module | Bluetooth 4.0 |
|
Charge | Protection requirements | Overcurrent protection | support |
|
Short circuit protection | support |
|
Over- voltage protection | support |
|
Environmental requirements | Operating temperature & humidity | 0℃ to +45℃, 0%RH to 95%RH |
|
Storage temperature and humidity | '-30℃ to +70℃
10%RH to 90%RH (non-condensing) @ Sea level shall below 5,000
meters |
|
Reliability requirements | MTB F | at least 50000 hours(25℃) |
|
Input power |
| 100-240V~ 50/60 Hz 1.5A Max |
|
Output power |
| 17V / 2.1A |
|
Safety |
| BSMI,NCC,CE,CCC |
|
Heat dissipation | Cooling method |
| Fan and radiator | Heat dissipation |
Battery | Built-in electric battery |
| 18650 *3 , 2600mAh |
|
Microphone | microphone |
| no |
|
Touch | Touch mode |
| Hand touch /pen touch |
|
Camera | Camera lens |
| Front 2 million pixels |
|
Sound | Built-in speaker | power | 3 W |
|
|
Remote control | remote control |
| 2.4G remote control (with voice) |
|
| Standby protection | Screen saver | Support screen saver |
|
Input | Chinese and English etc. | The system input in method |
|
System sound | Remote control key tone | Have |
|
| audio format | MP3/MP4/AAC/WAV/PCM/FLV |
|
Video signal | Audio and video decoding | MPEG4/MPEG2/MPEG1
DivX3.11/DivX 4.12/DivX 5.x/DivX 6/XviD
H.263/H265/H264/HEVC/MVC/AVS/AVS+/Motion JPEG/VP8/VP9 |
|
Support format | MP4/MKV/3GPP/DivX/FLV/MPEG/TS/AVI |
|
Audio decoding | MPEG1/MPEG2/AC3/EAC3/AAC-LC/HEAAC/WMA/VORBIS/DTS/LPCM/FLAC |
|
file | file format | doc,docx,pdf,txt,log,dot,dotx,xls,xlsx,csv,xlt,xltx,ppt,pptx,pps,ppsx,pot,potx |
|
Image Format | JPG, BMP, PNG |
|
Scale and format | Automatic identification of still image size | The image size is the aspect ratio |
|
Zoom mode support | Original ratio/4:3/16:9/Smart stretch/Zoom |
|
Upgrade method | Main system |
| USB, OTA |
|
Certification requirements |
|
| BSMI , NCC, CCC , CE |
|
Package | Outer box |
| TBD |
|
Outer packing list |
| TBD |
Courier box |
| TBD |
label |
| TBD |
Color box |
| TBD |
Color box label |
| TBD |
Package contains | Host size | Without packaging materials | 155 (L) *83 (W) *223 (H) |
|
Weight (excluding packaging materials) | Without packaging materials | 1.0 Kg |
|
Remote control |
| With voice, mouse function |
|
charger |
| AC 100-240V~ 50/60 Hz 1.5A Max DC 1 9 V, 2.1A |
|
Manual |
|
|
|
| Warranty Card |
| - |
|
